Features：

•Four channel full-duplex active optical cable

•Electrical interface only

•Multi-rate capability up to 11.5Gbps per channel

•Complies with QSFP MSA high-density form factor

•Reliable VCSEL array technology using multimode fiber

•Reach up to 500m@2.5Gbps and 80m@11.5Gbps

•Hot pluggable

•Built-in digital diagnostic functions

•Lower power dissipation: <0.9W per cable end

•0~70℃operating case temperature

Application

•InfiniBand QDR, DDR and SDR interconnects

•High performance and high productivity computer interconnects

•Data aggregation, backplane and proprietary density applications

•PCI-Express, SAS/SATA, and fiber Channel compatible interconnect

•Datacom and Telecom switch and router backplane connections

Code Data Rate (Gbps) Wavelength (nm) Power Consumption (W) Standard Length(m) Reach (m) State RHQ0225S 2.5 850 <0.8 25 500 Mass production RHQ0325S 3.125 850 <0.9 25 300 Mass production RHQ0520S 5 850 <0.8 20 150 Mass production RHQ0620S 6.25 850 <0.9 20 140 Mass production RHQ1015S 10 850 <0.8 15 100 Samples RHQ1115S 11.5 850 <0.85 15 80 Samples
